Home > Courses > Embedded System Design

PCB Design and Layout

Accelerate your Career

Learn PCB design using Cadence tools. Master schematic capture, layout, routing, and industry-standard practices for professional electronics design.

3 Modules
with Certifications
8:11 Hours
of Recorded Content
5.0 Ratings
by 1562 Learners
English
Language
Paid Course
Get this Course @ ₹999
1562 enrolled in this course

PCB Design and Layout

The PCB Design and Layout course introduces learners to the complete printed circuit board design process using Cadence. Beginning with PCB design fundamentals and schematic creation, the course gradually covers component footprint generation, BOM preparation, netlist integration, component placement, routing techniques, and manufacturing file generation. Designed for electronics students, embedded engineers, and hardware enthusiasts, this course provides practical exposure to industry-standard PCB development workflows used in product design and manufacturing. By completing hands-on exercises and guided demonstrations, learners will gain the confidence to transform electronic circuit concepts into production-ready PCB layouts suitable for embedded systems and commercial hardware applications.
MASTERING THE DATA SCIENCE LIFECYCLE

Comprehensive Syllabus Outline

A comprehensive curriculum designed to take you from beginner to professional.

M1

Module 1 — PCB Design Fundamentals

Introduction to PCB Design
Schematic, Footprint Adding, BOM, Netlist Creation
Schematic Diagram Creation for PCB
Footprint Creation for components in PCB

M2

Module 2 — Single Layer PCB

Single Layer PCB - Gerber Creating and viewing
Single Layer PCB - Routing
Single Layer PCB - Components Placement

M3

Module 3 — Double Layer PCB

Double Layer PCB

Capstone Project

Double-Layer PCB Design

Take a circuit from schematic to manufacturing files: create footprints, place and route single- and double-layer boards, and generate Gerbers ready for fabrication.

PROJECT

A double-layer PCB design.

Route a board on two copper layers with vias.

PROJECT

A single-layer PCB from schematic to Gerber.

Place, route and export a complete single-sided board.

CONCEPT

Schematics, BOM and netlist creation.

Capture circuits and prepare them for layout.

CONCEPT

Footprint creation for components.

Build accurate land patterns for every part.

CORE TOOLING MASTERY

Tech Stack

Master the primary professional software development packages and workflow tools.

KiCad
OrCAD / Allegro
Gerber Viewer
Schematic Capture
Bill of Materials
Career Impact

After this Course, You will be Able to

Observe the real-world utility outcomes you gain after program completion.

Explain the PCB design workflow from schematic to fabrication.
Draw schematic diagrams and add footprints.
Generate BOMs and netlists.
Create custom component footprints.
Place components and route single-layer boards.
Design double-layer PCBs and generate Gerber files.
