8051 Development Board Description
8051 Development Board integrates on board two UARTs, LEDs, keypads, an ADC input and LCD .Display to create a stand-alone versatile test platform. This board also has miniature Traffic light display for evaluation. User can easily engage in development in this platform, or use it as reference to application development.
Key Features of 8051 Development Board
- 40pin-ZIF Socket
- 8 No’s of Point LEDs (Logic Output)
- 8 No’s of Slide Switch (Digital Input)
- 4×4 Matrix Keypad
- 2X16 Character LCD
- 4 No’s of 7-Segment Display
- 2 No’s of Analog Input (Potentiometer)
- Stepper Motor Interface
- 2 Nos. of SPDT Relay
- DS1307 RTC with Battery-Backup
- 2 No’s of UART(RS232)
- Buzzer (Alarm), Interrupts Study, Reset Button
- SPI – Digital / Analog Output
- Serial EEPROM (I2C Devices)
- 128×64 Graphical LCD
- Digital Temperature Sensor(DS18S20)
- 40-Pin Expansion Connector
- ISP Programmer for NXP | Dallas MCU
- Traffic Light Controller Modules
Benefits of 8051 Development Board
- RTOS Support
- Evaluate Real Time Applications
- Supports Embedded C, ASM
- ISP Programming | SPI | I2C Communications
- Facility to interface external devices
MCU
- Devices :
- AT89S51/52/825x (Atmel)
- P89V51Rxx (NXP)
- DS89C420/430/450 (Dallas)
- Memory : 64K FLASH – Program
- Clock : 12MHz crystal, Max = 25 MHz
8051 Development Board Kit Includes
- P89V51RD2 8051 Development kit
- Power Adaptor
- RS232 Cable
- User Guide: HW/SW
- CD Contains:
- Code
- Programmer
- IDE
- Datasheets
